Touch Screen

Capacitive touch

Display Size

7” LCD

Resolution

1920*1200

HDR

HLG; ST2084 300/1000/10000

Brightness

2000cd/m²

Aspect Ratio

16:10

Contrast

20小时 0分 1秒

Color Space

100% BT.709

Viewing Angle

160°/160°(H/V)

Video Input SDI

1×3G

Video Input HDMI

1×HDMI 2.0

Video Loop Output SDI

1×3G

Video Loop Output HDMI

1×HDMI 2.0

Supported In / Out Formats SDI

1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60…

Supported In / Out Formats HDMI

2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60…

Audio In/Out HDMI

8ch 24-bit

Audio In/Out Ear Jack

3.5mm – 2ch 48kHz 24-bit

Audio In/Out Built-In Speakers

1

Operating Power

≤16W (15V)

DC In

DC 7-24V

Operating Temperature

0℃~50℃

Storage Temperature

-20℃~60℃

Dimension(LWD)

186mm × 128mm × 29mm

Weight

0.520kg
