The Intelix AVO-MIC-F microphone balun set transmits a preamplified microphone signal and phantom power up to 2,500 feet over standard twisted pair structured cabling, such as Cat 5 or Cat 6. The AVO-MIC-F includes a rack-mountable send balun, rack-mountable receive balun, and a power supply; the set may be powered on either the send or receive end. The AVO-MIC-F is ideal for corporate facilities, churches, schools, auditoriums, and almost any other situation involving microphone audio signal distribution.

Technical Specifications

• Max Distance 2,500 feet
• Bandwidth 20 Hz to 20 kHz
• Power 24 VAC; the system may be powered on either the send or receive end
• Power Connector DIN Connector
• Phantom Power 24 V
• System Gain 0 to 60 dB
• Impedance 600 ohms, balanced
• Isolation 500 V
• Nominal Level 1.0 V
• Insertion Loss 1 dB
• Common Mode Rejection Greater than 40 dB
• Cable Cat 5, Cat 5e, Cat 6, and Cat 7 compatible
• Connectors One (1) 3-pin screw terminal to one (1) RJ45
• Enclosure Black plastic
• Dimensions 4.3" x 2.5" x 1.0"
• Shipping Weight 2.0 lbs.
• Pin Out Channel 1: 1 & 2, pair 2
  Power: 4 & 5, pair 1
• Temperature Operating: 32 to 131 degrees F
  Storage: -4 to 185 degrees F
  Humidity: up to 95%
• Warranty 2 years
